EroVista wood light poles & wood bollards

RESIDENTIAL  -  COMMERCIAL  -  PARKS & RECREATION  - CATENARY LIGHTING

EroVista light poles are manufactured to provide decades of outdoor service-life while offering an eco-friendly, attractive, functional and economic solution to a designer’s outdoor site lighting needs.

EroVista Capability Statement

Lengths & Dimensions

Standard section sizes:

          5” x 5-1/2” up to 18' fixture height above soil grade or top of foundation

          6-3/4” x 6-3/4” up to 24' fixture height above soil grade or top of foundation

          8-1/2” x 8-1/4”  up to 28' fixture height above soil grade or top of foundation

Center wire route:  Manufactured with a 1” x 1-1/4" full-length center wire route designed to protect and conceal electrical wiring.

Bollards

EroVista wooden bollards are beautiful, durable and tough.  Direct embedment installation eliminates the cost of foundations and offers higher lateral stability and stiffness.  EroVista wood bollards are custom manufactured and fabricated to meet the project’s architectural design and fixture mounting requirements.

Surface Textures

·  Smooth (standard)

·  Rough sawn

Fabrication Styles

·  Radiused edges (1/4" standard)

·  1/2" radiused edges

·  1" chamfered edges

Factory Staining

EroVista light poles can be pre-stained or stained/painted in the field to achieve a desired color.  When painted or stained, periodic retreatment may be required to maintain the original color.  If left unstained, the wood will weather to a natural attractive silver-gray color.  Customers choosing to purchase light standards pre-stained must specify a Sherwin-Williams SuperDeck Semi-Transparent Stain ( SW _ _ _ _ color number).  It's important to note that stain color will vary depending on wood species and will differ from Sherwin-Williams color charts.

Tenon Top & Protective Caps

Specify a MC metal tenon cap to accommodate top mounted luminaries or a PC protective cap for side-mounted luminaries.   All metal cap hardware is made from powder coated 10 gauge steel, powder coated flat black.

Side Mount Options

Cross arms by others or EroVista's CA cross arms can be specified for side mount fixture applications.  CA cross arms can be custom manufactured to include a vertical tenon at the end of the arm.

Metal Base Plates

For pedestal mount installations, specify metal base plates (BP or BP-H base plates with a hand hole).  AC cover skirts are also available to conceal anchor bolts.  Anchor bolts and pedestal foundations are supplied by others and should be designed by a licensed professional engineer per local soil conditions and building codes.  All metal BP, BP-H and AC hardware is made from primary steel and powder coated flat black.

Direct Embedment

Specifiers can consider directly embedding EroVista’s poles into the ground, eliminating the need for costly pedestal foundations.

When embedding any wood product below the surface, it’s essential to assess soil conditions, moisture levels, potential insect activity, and geographical deterioration zones.

Packaging & Shipping

·  EroVista light poles are shipped job lot wrapped or can be individually paper wrapped at an additional cost.
